High-Reliability Copper-Aluminum Composite Busbar for Large-Scale Energy Storage Systems

A leading energy storage system integrator faced a critical challenge while designing a new generation of containerized storage units: they needed a busbar solution capable of handling extremely high currents (exceeding 2000A) while offering superior heat dissipation and lightweight properties to enhance overall system efficiency and power density.
ShenCheng XingChuang Industrial, leveraging its profound expertise in electrical connectivity, provided an innovative Copper-Aluminum Composite Busbar design. Our process began with simulation analysis to optimize the busbar's cross-sectional profile and laminated structure for optimal current distribution and thermal management. We then employed precision stamping dies to ensure exact bonding surfaces between the copper and aluminum layers. The key breakthrough was the application of Polymer Diffusion Welding technology, which creates an atomic-level bond between the two dissimilar metals, guaranteeing exceptionally low contact resistance and long-term reliability.
The delivered component not only met all client specifications for electrical and mechanical performance but also achieved a 35% reduction in weight and improved heat dissipation efficiency by over 20% through its innovative design and manufacturing process. This solution successfully empowered our client to gain a competitive edge in their energy storage systems and established a long-term partnership for core component supply.
